N2183-2F-X1 10G 2-fiber FTX710

Protection

Supports local encryption key management for NVMe static data CBE solution

Performance

Support PCIe4.0 Tri-mode design solution Support up to 15.75GB/s throughput Up to 8GB DRAM acceleration cache.

Application

Data center Enterprise-level hyperscale applications.

Name		Specifications
Network card information	Network card model	N2183-2F-X1
	Network card type	Label
	Network card speed	10GE
	Port Type	Optical port
	describe	10G Ethernet 2-port optical network card
	Chip Type	Intel FTX710-BM2
	PCIe Bus	PCI Express v3.0 (8 GT/sec)X8
Basic Features	Controller	Intel FTX710-BM2
	Cable Media	optical fiber
	Fiber Type	10GBase-SR, 10GBase-LR, 10GBase-Cu
	Baffle height	Full-height and half-height configurations
	Power consumption (max)	7.4W
	Port Type	2*SFP+
	PCIe Bus	PCI Express v3.0 (8 GT/sec)X8
	Port rate	10/1 Gb/s
	Power supply	PCIe Power Delivery
	Compatible operating systems	Windows10/8.1/8, Windows Server2019/2016/2012/2008/2003, Linux
Technical Parameters	Ethernet Power Management	Yes
	PXE support	Yes
	SFI/KR/KX4/XAUI/SGMII support	Yes
	Jumbo Frames Support	Yes
	Traffic shaping support	Yes
	Data Center Protocol Acceleration Support	Yes
	Network protocol acceleration	TCP/UDP/IP offload
	Virtual Machine (SR-IOV) Support	Yes
	FCoE	No
